Features：
(1)Automatic sharpening device
(2)Automatic lubrication system
(3)Fan safety protection device and switch safety cover
| Blade Size | 6" , 7" , 8" , 9" , 10" , 11-1/2" , 13" |
|---|---|
| Cutting Height | Less 2” from Blade Size |
| Power | 1 Phase 500 W (0.65HP) ，3 Phase 700W (0.95HP) |
| Speed | Single Speed:50Hz / 2850 RPM, 60Hz / 3450 RPM ， Dual Speed: 50Hz /2850/1425RPM, 60Hz /3450/1725 RPM |
| Rated Voltages | 1 Phase 100V, 110/120V, 220/240V ， 3 Phase 220V, 380V, 415V(400/440) * In ordering please specify : blade size, voltage & Hz. |
| Stroke | 1-1/2"(38mm) |
| Accessories | Machines are fitted with alloy blade. Accessory bag with one piece extra blade, plug, oil pan, abrasive sharpener belts, and tools. |
| Optional Blades | HSS, Carbon Steel, Teflon Coated, Wave Knife. |
| Net weight / Gross weight | 16 Kgs /19 Kgs |
| Package/Set/CTN | 80*42*33 CM |
Features：
(1)Automatic sharpening device
(2)Automatic lubrication system
(3)Fan safety protection device and switch safety cover
| Blade Size | 6" , 7" , 8" , 9" , 10" , 11-1/2" , 13" |
|---|---|
| Cutting Height | Less 2” from Blade Size |
| Power | 1 Phase 700W(0.95HP) ，3 Phase 900W(1.25HP) |
| Speed | Single Speed:50Hz / 2850 RPM, 60Hz / 3450 RPM， Dual Speed: 50Hz /2850/1425RPM, 60Hz /3450/1725 RPM |
| Rated Voltages | 1 Phase 100V, 110/120V, 220/240V ， 3 Phase 220V, 380V, 415V(400/440) * In ordering please specify : blade size, voltage & Hz. |
| Stroke | 1-1/2"(38mm) |
| Accessories | Machines are fitted with alloy blade. Accessory bag with one piece extra blade, plug, oil pan, abrasive sharpener belts, and tools. |
| Optional Blades | HSS, Carbon Steel, Teflon Coated, Wave Knife. |
| Net weight / Gross weight | 17 Kgs / 20Kgs |
| Package/Set/CTN | 82*42*33 CM |
Features：
(1)Automatic sharpening device
(2)Automatic lubrication system
(3)Fan safety protection device and switch safety cover
| Blade Size | 5" , 6" |
|---|---|
| Cutting Height | 3 1/2”(85MM) 4 1/2”(110MM) |
| Power | 200W (0.25HP) |
| Speed | 50Hz/2850RPM,60Hz/3450RPM |
| Rated Voltages | 1 Phase100V 110/120V 220/240V ， 3 Phase 220V 380V 415V(400/440) * In ordering please specify : blade size, voltage & Hz |
| Stroke | 1"(25mm) |
| Optional Blades | Carbon Steel, Teflon Coated, Wave Knife |
| Net weight / Gross weight | 10 Kgs / 12.5 Kgs |
| Package/Set/CTN | 53*32*22 CM |
